Product Details
Product name
PPS_MFS-100Lw [v1.6]
IMD-PQS Code
E007-010
Status
Prequalified
Date of acceptance
14 Jun 2024
Product description
Voltage Stabiliser (Integrated)
Manufacturer
Thyratron Electronic Applictions SA
Manufacturer Reference
PPS_MFS-100Lw [v1.6]
Country of Manufacture
Greece
Address
Kydonies, Erymanthos, Achaia 25008 Patra
Greece
Greece
Telephone
+30 2694 062 010
Email
Website address
Valid until
31 May 2026
Specifications
Product specifications - Main
Power Input (W)
0.73
Product specifications - Additional
Nominal Input Voltage (V)
230.00
Nominal Output Voltage (V)
230.00
Input frequency regulation range (Hz)
47-63
Input Voltage Regulation Range (V)
110-285
Output Current (A)
3.20
Short Circuit Protection Type
Internal
Overload Protection Type
Internal
Impulsive Transient Protection (kA)
10.00
Maximum Rated Ambient Temp (°C)
43.00
Minimum Rated Ambient Temp (°C)
-5.00
Mode of operation
Other
Mode of operation (Other)
AC to AC voltage stabilizer
CE marking
Yes
Price and shipping
Minimum order
1.00
Price
90 $US
Year of base price
2025
Incoterms
EXW
Quality standard
Quality Standard
Other
Quality standard (Other)
ISO9001:2015; ISO14001:2015
Specification Reference
WHO/PQS/E007/VS01.6
Verification
Verification Laboratory
Labor SA
Address
Ethnikis Antistaseos 84, Pallini, P.C. 15351, Greece
Greece
Greece
Telephone
+30 2106033377
Email
Verification Report Reference
VoC 0565.011.3.05
Document Details
Shipping Weight: ECU: 11Kg/carton, Transformers: 25Kg/Carton
Output Voltage Accuracy (%): +10% or -15%
Nominal Input Frequency (Hz): 50 or 60 Hz
Nominal Output Frequency (Hz): 50 - 60 Hz
Relative Humidity Rating (%): 5 - 95% RH, non-condensing
Weight per Unit (Kg): 0.270Kg ECUs, 3.970Kg Transformer, Total 4.240Kg
Units per package 36 ECUs/carton, 6 Transformers/carton
OverVolt.EnduranceElectricalWithstand(V): 60 - 500VAC
Weight per Package (Kg): 10.5kg ECUs(36qty)/carton, 24.5kg Transformers(6qty)/carton
External dimensions height (mm) 32.5mm/ECU, 131mm/Transformer
External dimensions length (mm) 121mm/ECU, 94.5mm/Transformer
External dimensions width (mm) 114mm/ECU, 108.5mm/Transformer
