SF - Immunization Devices
Download file
Product Details
Product name
RCW25FF
IMD-PQS Code
E004-090
Status
Prequalified
Date of acceptance
19 Feb 2026
Appliance type
E004
Product description
Freeze-preventive cold box
Manufacturer
B Medical Systems Sarl
Manufacturer Reference
RCW25FF
Country of Manufacture
Luxembourg
Address
17 Op der Hei
Hosingen
Luxemburg
Luxembourg
Hosingen
Luxemburg
Luxembourg
Telephone
+ 35 2 92 07 311
Email
Website address
Valid until
31 May 2027
Specifications
Product specifications - Main
Vaccine storage capacity (Litre)
10.40
External dimensions length (mm)
700.00
External dimensions height (mm)
503.00
External dimensions width (mm)
542.00
Internal dimensions (length, mm)
263.00
Internal dimensions (height, mm)
292.00
Internal dimensions (width, mm)
330.00
Cold life at +43°C * (hrs:mn)
110:37
Warm life at - 20°C *(hrs:mn)
65:53
Weight empty(Kg)
20.7500
Weight fully loaded (Kg)
40.61
Minimum Rated Ambient Temp (°C)
15.00
Coolant packs
yes
Number coolant packs
18.00
Type coolant packs
Water packs
Model coolant pack
0.6L
Coolant packs supplied
Yes
Product specifications - Materials & construction
Insulation materials
Polyurethane foam, foaming agent: Cyclopentane
Insulation thickness (mm)
90-105 mm
Container type
Cold box
External materials
Polyethylene
Internal lining materials
Aluminum, ABS, EPP, PCM Polymer
Lid type fixing
Fixed hinges
Price and shipping
Shipping volume (m3)
0.221
Shipping weight (kg)
23.00
Shipping weight per carton(kg)
23
Pieces per package
1
Minimum order
1.00
Year of base price
2026
Incoterms
EXW
Quality standard
Quality Standard
ISO 9000: 2000
Specification Reference
Applicable PQS specification: E004/CB05-VP.3
Applicable PQS VP(s):
Applicable PQS VP(s):
Product Sites
B Medical Systems Sarl
17 Op der Hei
Hosingen,
Luxemburg
L-9809
Luxembourg
Document Details
Accessories available as an option: Berlinger loggers; LogTag loggers
