Product Details
Product name
TPVC 46 LFF
IMD-PQS Code
E004-066
Status
Prequalified
Date of acceptance
18 Jan 2023
Appliance type
E004
Product description
Freeze-preventive vaccine carrier LR
Manufacturer
TRIMURTI PLAST CONTAINERS PRIVATE LIMITED
Manufacturer Reference
TPVC 46 LFF
Country of Manufacture
India
Address
31/833, GANESHNAGAR, DHANKAWADI
PUNE
Maharashtra
India
PUNE
Maharashtra
India
Telephone
+91 98220 22312
Email
Website address
Valid until
31 May 2026
Specifications
Product specifications - Main
Vaccine storage capacity (Litre)
1.50
External dimensions height (mm)
305.00
External dimensions width (mm)
310.00
Internal dimensions (length, mm)
94.00
Internal dimensions (height, mm)
170.00
Internal dimensions (width, mm)
94.00
Cold life at +43°C * (hrs:mn)
30:29
Warm life at - 20°C *(hrs:mn)
16:28
Weight empty(Kg)
3.9700
Weight fully loaded (Kg)
7.90
Minimum Rated Ambient Temp (°C)
15.00
Coolant packs
0.6 L
Number coolant packs
4.00
Type coolant packs
Water packs
Model coolant pack
TIP-6
Coolant packs supplied
Yes
Product specifications - Materials & construction
Insulation materials
Polyurethane
Insulation thickness (mm)
34 mm
External materials
Polyethylene
Internal lining materials
Polyethylene
Lid type fixing
Fixed hinges
Comments
Vaccine storage dimensions (cm): 9.4 (L) x 9.4 (W) x 17.0 (H)
Price and shipping
Shipping weight per carton(kg)
18
Pieces per package
2
Minimum order
4.00
Price 1
<10 units: 42.5 USD
Price 2
11-100 units: USD 42.5
Price 3
>100 units: USD 42.5
Year of base price
2023
Incoterms
EXW
Quality standard
Quality Standard
Other
Quality standard (Other)
ISO 9001:2008
Specification Reference
Applicable PQS specification: E004/VC02.1
Applicable PQS VP(s): E004/VC02-VP.1
Applicable PQS VP(s): E004/VC02-VP.1
Subject to Field Validation
N/A
Verification
Verification Laboratory
Intertek India
Address
Intertek India Private Limited E-20, Block B1, Mohan Cooperative Industrial Estate Mathura Road New Delhi -110044 India
India
India
Telephone
+91-9820213510
Email
Verification Report Reference
CE-JOB-NDA-22-001981-001
Product Sites
TRIMURTI PLAST CONTAINERS PRIVATE LIMITED
31/833, GANESHNAGAR, DHANKAWADI
PUNE,
Maharashtra
RAJESH411043
India
