E003-169

SF - Immunization Devices
Download file
E003-169.pdf
E003-169.json
Product Details
Product name
TCW 40F SDD
IMD-PQS Code
E003-169
Status
Prequalified
Date of acceptance
28 May 2026
Appliance type
E003
Product description
Solar direct drive waterpacks freezer
Manufacturer
B Medical Systems Sarl
Manufacturer Reference
TCW 40F SDD
Country of Manufacture
Luxembourg
Address
17 Op der Hei
Hosingen
Luxemburg
Luxembourg
Telephone
+ 35 2 92 07 311
Email
info@bmedicalsystems.com
Website address
www.bmedicalsystems.com
Valid until
31 May 2027
Specifications

Product specifications - Main

Climate zone
Hot
Relative Humidity (Min)
30.00
Relative Humidity (Max)
85.00
Hold over time (hours:mn)
12:00
External dimensions length (mm)
780.00
External dimensions width (mm)
1055.00
External dimensions height (mm)
910.00
Appliance tested at (°C)
43.00
Performance at" (°C)
43.00
Fuel and refrigeration cycle
Electric - compression
Energy source
Solar Direct Drive
Lining
PCM
Energy Consumption During Freezing (kWh/24h)
0.6000
Energy Consumption Cool Down (kWh/24h)
0.6250

Product specifications - Additional Refrigerator

Solar radiation ref period (kWh/m2/day)
3.50

Product specifications - Additional Freezer

Freezer type
Rapid water-pack freezer
Freezer's gross volume (Litres)
64.00
Waterpack freezing capacity (Kg/24 hrs)
3.60
Waterpack storage capacity (Litres)
18.00
Comments
Prices include the solar system: SG490 RGA
Energy sources: nominal 37 V DC solar electric array. Minimum power 490 watts at solar radiation reference period 3.5 kWh/m2/day

Freezer net volume: 50 - 110 L
Range freezing capacity: < 5 kg/24h
Range waterpack storage capacity: 20 - 100L

Water-pack freezing capacity: 18kg = 30 Water-packs 0.6L
List of accessories
2 Keys
2 spacers
8 waterpacks 0.6l
8 waterpack holders
8 waterpack caps
1 brush
1 compass
1 wrench
1 basket
1 user manual
1 recycling instructions
List of spare parts, Reference & Price
296.9768.82 VCC COLD CHAIN CONTROLLER
296.9705.37 POWER MANAGEMENT MODULE
296.9805.13 SENSOR TEMP REGULATION
296.9805.18 SENSOR HUMIDITY REFRIGERATOR
296.9705.38 EBOX
292.9960.13 FAN
296.9702.17 COMPRESSOR

Other parts are available as spares on request.

Price and shipping

Shipping volume (m3)
0.908
Shipping weight (kg)
122.00
Minimum order
1.00
Units per package
1.00
Incoterms
EXW
Price 1
For quantities between 1-39 pcs: 7,490 EUR EXW
Price 2
For quantities between 40-99 pcs: 7,116 EUR EXW
Price 3
For quantities above 100pcs: 6,741 EUR EXW
Year of base price
2026

Quality standard

Quality Standard
Other
Quality standard (Other)
ISO 9001 & ISO 13485
Specification Reference
Applicable PQS specification: E003/FZ03.3
Applicable PQS VP(s): E003/FZ03-VP.1

Verification

Verification Laboratory
Re/Gent B.V
Address
Lage Dijk 22
Netherlands
Telephone
+31492 476365
Email
patrick.beks@re-gent.nl
Verification Report Reference
Re/Gent B.V. BM34/25335/V1
Product Sites
B Medical Systems Sarl
17 Op der Hei
Hosingen,
Luxemburg
L-9809
Luxembourg
