Product Details
Product name
VLS 086A RF AC
IMD-PQS Code
E003-168
Status
Prequalified
Date of acceptance
26 May 2026
Appliance type
E003
Product description
Combined icelined refrigerator/waterpacks freezer
Manufacturer
Vestfrost Solutions
Manufacturer Reference
VLS 086A RF AC
Country of Manufacture
Denmark
Address
A/S Vestfrost Falkevej 12
Esbjerg Ø
Syddanmark
Denmark
Esbjerg Ø
Syddanmark
Denmark
Telephone
+45 7914 2527
Website address
Valid until
31 May 2027
Specifications
Product specifications - Main
Climate zone
Hot
Minimum rated ambient temperature (°C)
5.00
Humidity Control
Passive
Freeze protection
Grade A
Hold over time (hours:mn)
130:17
External dimensions length (mm)
1190.00
External dimensions width (mm)
655.00
External dimensions height (mm)
925.00
Appliance tested at (°C)
43.00
Performance at" (°C)
43.00
Ambient temperature during testing (°C)
43.00
Fuel and refrigeration cycle
Electric - compression
Energy source
AC
Lining
Ice-lined
Energy Consumption During Freezing (kWh/24h)
1.5750
Energy Consumption Intermittent Power (kWh/24h)
1.3380
Energy Consumption Cool Down (kWh/24h)
1.3380
Energy Consumption Continuous Power (kWh/24h)
1.3650
Product specifications - Additional Refrigerator
Refrigerator vaccine storage capacity(L)
57625.000
Refrigerator's gross volume (Litres)
77.000
Refrigerant type
R600a
Solar radiation ref period (kWh/m2/day)
3.50
Product specifications - Additional Freezer
Freezer type
AC
Freezer net volume
50
Freezer's gross volume (Litres)
50.00
Waterpack freezing capacity (Kg/24 hrs)
2.40
Waterpack storage capacity (Litres)
16.80
List of accessories
1Appliance supplied with, 1 x Vaccine storage top basket, bottom grating; Electronic
temperature reading from 5" display, if L2/3 - 5" Touch Display; Locking lid + keys; 1x instruction manual 1x technical/service manual if EMS L2/3, additional EMS instruction manuals
temperature reading from 5" display, if L2/3 - 5" Touch Display; Locking lid + keys; 1x instruction manual 1x technical/service manual if EMS L2/3, additional EMS instruction manuals
List of spare parts, Reference & Price
1x 7020545 Voltage stabilizer controller
1x 7021143 VLS Thermostat
1x 8-036510021 Compressor - Complete, incl. Run. Cap, starting device
1x 7090546 Sensor kit, 1050mm
1x 7021143 VLS Thermostat
1x 8-036510021 Compressor - Complete, incl. Run. Cap, starting device
1x 7090546 Sensor kit, 1050mm
Price and shipping
Shipping volume (m3)
1.17
Shipping weight (kg)
160.00
Minimum order
1.00
Units per package
1.00
Incoterms
FCA
Price 1
4.769
Price 2
4.629
Price 3
4535
Year of base price
2025
Quality standard
Quality Standard
Other
Quality standard (Other)
ISO 9001:2015; ISO 14001:2015; ISO 45001:2018
Specification Reference
PQS specification: E003/RF03.7 PQS VP: E003/RF03-VP.5
Verification
Verification Laboratory
Danish Technological Institute
Address
Gregersensvej DK-2630 Taastrup Danemark
Denmark
Denmark
Telephone
+45 72202472
Verification Report Reference
300-KLAB-24-155
Product Sites
Vestfrost Solutions
A/S Vestfrost Falkevej 12
Esbjerg Ø,
Syddanmark
DK-6705
Denmark
Document Details
APP, containing various installation/service features.
As option the appliance can be supplied with Vestfrost in-built EMS Level 2 and 3; with following features:
1: 5” touch display 2: 3X internal temp. sensors 3: ambient temp. 4: compressor power
5: lid opening alarm 6: GPS coordinates via Google maps 7: 1X USB 5V
Solar harvesting port. All data collected/logged is automatically via GSM uploaded to Vestfrost
EMS performance data-portal, and/or can be accessed onsite from the touch screen menu, or USB C data access port.
