SF - Immunization Devices
Download file
Product Details
Product name
HAIER Cold rooms and Freezer rooms
IMD-PQS Code
E001-003
Status
Prequalified
Date of acceptance
25 Oct 2011
Appliance type
E001
Product description
Cold rooms and freezer rooms
Manufacturer
Qingdao Haier Biomedical Co., Ltd
Manufacturer Reference
HAIER Cold rooms and Freezer rooms
Country of Manufacture
China
Address
No.280 Fengyuan Road High-tech Zone
Qingdao
Shandong
China
Qingdao
Shandong
China
Telephone
+86-15066227057
Website address
Valid until
31 May 2025
Specifications
Product specifications - Main
Temperature Zones
Multizone
Pre-qualified regions
All regions
Auto defrost
Yes
Enclosure construction options
Cold room sizes available (largest, m3)
10.00
Freezer room sizes available (L, m3)
10.00
Door frame heating available
Yes
Panel insulation material
Polyurethane
Panel jointing system
Tongue and groove, cam lock
Shelving system
Adjustable shelves only
Shelving material
Steel only
Shared wall construction
Yes
Strip curtain available
Yes
Pressure release valve (FR only)
Yes
Floor panel heater mat (FR only)
Yes
Wall/Celling Panel Finish
Zinc polyester powdered coated
Floor panel finish
Rubber corrugated
Type of Foaming Agent
Polyurethane
Product specifications - Equipment options
Refrigerant
R448a or R455a
Refrigeration unit types
Monoblock
Lighting system
Tungsten
Duty sharing
Manual changeover
Cold climate protection CR
No
Evaporator plume guard CR
Yes
ISO 9001/13485 certified
Other
ISO 9001/13485 certified (Other)
ISO 9001;ISO 13485;IEC 60335-1
Electric Safety Compliant To IEC 60335-1
Yes
High/low voltage protection
No
Voltage,Frequency,Phasing options?
Yes
Voltage Regulator Available?
No
Surge Protection Available?
No
Cut-out system
Yes
Product specifications - Temperature monitoring & alarm options
Temperature recording system
Event logger
Alarm system
Yes
ISO 14001 certified
Yes
Warranty, installation and maintainence
Maintenance service
Advisory service
Installation service
Advisory service
Quality standard
Specification Reference
Applicable PQS specification:
Applicable PQS VP(s):
Applicable PQS VP(s):
Product Sites
Qingdao Haier Biomedical Co., Ltd
No.280 Fengyuan Road High-tech Zone
Qingdao,
Shandong
266109
China
Document Details
Event logger: Haier Intelligent Recorder
Power options: DC and AC compressor optional
Freezer room sizes: >10 m3
