SF - Immunization Devices
Download file
Product Details
Product name
DW-25W300
IMD-PQS Code
E003-061
Status
Prequalified
Date of acceptance
11 Feb 2015
Appliance type
E003
Product description
Vaccine/Waterpack freezer
Manufacturer
Qingdao Aucma Global Medical Co.,Ltd.
Manufacturer Reference
DW-25W300
Country of Manufacture
China
Address
315 Qianwangang Road, Economic &Technological Development Zone,
Qingdao
Shandong
China
Qingdao
Shandong
China
Telephone
+86 532 86763602
Email
Website address
Valid until
31 May 2026
Specifications
Product specifications - Main
Climate zone
Hot
Minimum rated ambient temperature (°C)
5.00
Hold over time (hours:mn)
58:36
External dimensions length (mm)
945.00
External dimensions width (mm)
790.00
External dimensions height (mm)
1226.00
Performance at" (°C)
43.00
Fuel and refrigeration cycle
Electric - compression
Energy source
Electric Mains 220-240V 50/60Hz
Lining
Regular
Energy Consumption Cool Down (kWh/24h)
3.5400
Energy Consumption Continuous Power (kWh/24h)
3.3700
Product specifications - Additional Refrigerator
Refrigerator vaccine storage capacity(L)
240.000
Refrigerant type
R600a
Solar radiation ref period (kWh/m2/day)
1.00
Product specifications - Additional Freezer
Freezer type
Rapid water-pack freezer
Freezer's gross volume (Litres)
300.00
Waterpack freezing capacity (Kg/24 hrs)
38.30
Waterpack storage capacity (Litres)
44.30
List of accessories
0
List of spare parts, Reference & Price
Included in the UNICEF Supply Division spare parts kit:
1 No. Compressor
1 No. Electronic thermostat
1 No. Fan
Other parts are available as spares on request.
1 No. Compressor
1 No. Electronic thermostat
1 No. Fan
Other parts are available as spares on request.
Price and shipping
Shipping volume (m3)
0.92
Shipping weight (kg)
75.00
Price 1
1-99 units, USD 540
Price 2
100-199 units, USD 520
Year of base price
2016
Quality standard
Quality Standard
Other
Quality standard (Other)
ISO 9001:2008
Specification Reference
Applicable PQS specification: E003/FZ01.2
Applicable PQS VP(s): E003/FZ01-VP.2
Applicable PQS VP(s): E003/FZ01-VP.2
Verification
Verification Laboratory
CHEARI
Address
#29 Xia Jie Street, Xuan Wu district Beijing 100053 R. P. de Chine
China
China
Telephone
+86 1063162443
Email
Verification Report Reference
WB-14-041
Product Sites
Qingdao Aucma Global Medical Co.,Ltd.
315 Qianwangang Road, Economic &Technological Development Zone,
Qingdao,
Shandong
266510
China
Document Details
Freezing capacity range: > 15 kg/24h
Range of holdover time: 51 - 100 hours
Range vaccine storage capacity: 220L - 250L
Range waterpack storage capacity: > 200
